Digital Roll to Roll Printing Machine

Digital Roll to Roll Printing Machine

CMYK + White ink + Digital UV Varnish achieves different levels of gloss and glazing effect by controlling different combinations.

Digital Roll to Roll Printing Machine
Digital Roll to Roll Printing Machine
Digital Roll to Roll Printing Machine
Digital Roll to Roll Printing Machine
Digital Roll to Roll Printing Machine
Digital Roll to Roll Printing Machine
PrintheadOn-demand piezoelectric printhead
Resolution600*600dpi, 1200*600dpi, 1200*1200dpi
Ink TypeLED curable UV Ink
Max printing width210mm, 320mm, 420mm (customerized size)
Max Printing Speed70m/min
Printing TableRoll to roll
Printing Materialcoated paper, metal film, art paper, coated and uncoated paper, all kinds of adhesive, PP, PE, PET film
Registration Accuracy±0.01mm
Equipment size4100mm*1400mm*2100mm
Equipment weight4000kg
PowerHost + Platform: 3 phase 380V 8KWUV Curing: 1 phase 220V 2KW
Corona3KW
Air supply0.6KPa
PlatformFull servo control
Recommended
Digital One Pass Carton Box Printing MachineDigital One Pass Food Box Paper Cup Printing MachineDigital Bag Printing MachineDigital Sheet-fed Full Color Inkjet Printing Machine

Frequently Asked Questions

What are the key specifications of Digital Roll to Roll Printing Machine?

Resolution: 600*600dpi, 1200*600dpi, 1200*1200dpi; Ink Type: LED curable UV Ink; Max printing width: 210mm, 320mm, 420mm (customerized size); Max Printing Speed: 70m/min; Printing Table: Roll to roll; Printing Material: coated paper, metal film, art paper, coated and uncoated paper, all kinds of adhesive, PP, PE, PET film; Registration Accuracy: ±0.01mm; Equipment size: 4100mm*1400mm*2100mm; Equipment weight: 4000kg; Corona: 3KW; Air supply: 0.6KPa; Platform: Full servo control
