Ink Roller Cooling System
1. Stable temperature control from circulating oil will improve print quality.
2. Prevent oxidation build-up within the ink roller.
3. Prevent water condensation on the ink roller.
4. Malfunction auto detection and warning indicators.
| Model | GREENMAC-RO |
|---|---|
| Temperature Control Range | 15-35 degree C |
| Cooling Capacity | 14KW/h |
| Total Power Output | 6.68KW |
| Maximum Operating Current | 16A |
| Refrigeration Circuit | 1 |
| Energy Regulation Method | Capillary Tube |
| Compressor Power | 4.05KW |
| Cooling Fan Power | 0.48KW |
| Internal Circulation Pump Power | 0.75KW, Flow Rate L: 160 (l/min), Maximum Head H: 25 (m) |
| External Circulation Pump Power | 1.5KW, Flow Rate L: 200 (l/min), Maximum Head H: 30 (m) |
| Water Tank Capacity | 80L |
| Cold Water Pipe Diameter | G1" 1 Inlet 1 Outlet |
| Refrigerant | R22 |
| Filling capacity | 4.8KG |
| Total weight | 220KG |
| Dimensions | L1.4xW0.7xH1.55m |
| Power Supply | 3 phase 380V 50HZ |
