CTP Plate Processor for CTP Machine
| Model | PROCEMAC | |||
|---|---|---|---|---|
| 90PT | 110PT | 125PT | 150PT | |
| Processing Plate | thermal CTP plate or CTCP plate | |||
| Capacity | 12-90 m/hr | |||
| Plate Width (mm) | 880 | 1100 | 1240 | 1490 |
| Min. Plate Length (mm) | 300 | 400 | 400 | 400 |
| Plate Thickness (mm) | 0.15-0.4 | |||
| Tank Content, developer (L) | 45 | 55 | 65 | 75 |
| Tank Content, wash (L) | 35 | 40 | 45 | 60 |
| Adjustable Temperature, dev | 0 to 40 degree C. adjustable | |||
| Adjustable Temperature, dry | normal temperature to 70 degree C. | |||
| Diameter of Roller | 60mm | |||
| Dev. Replenishment | 0-1L per plate | |||
| Dev. Heating-up Rate | 0.5 degree C. per minute | |||
| Power Supply | 220V 1 phase 50-60Hz | |||
| Power Consumption (kwh) | 3.5 | 4 | 4.5 | 5 |
| Net Weight (kg) | 500 | 600 | 700 | 800 |
Recommended
Frequently Asked Questions
What are the key specifications of CTP Plate Processor for CTP Machine?
Processing Plate: thermal CTP plate or CTCP plate; Capacity: 12-90 m/hr; Plate Width (mm): 880; Min. Plate Length (mm): 300; Plate Thickness (mm): 0.15-0.4; Tank Content, developer (L): 45; Tank Content, wash (L): 35; Adjustable Temperature, dev: 0 to 40 degree C. adjustable; Adjustable Temperature, dry: normal temperature to 70 degree C.; Diameter of Roller: 60mm; Dev. Replenishment: 0-1L per plate; Dev. Heating-up Rate: 0.5 degree C. per minute
