Toray TORELIEF Dry Offset Plate Processor
Automatic plate processors with low-maintenance design use up to 80% less chemicals and wash water than traditional "wet" lithographic plate processors. Since chemicals such as high alkaline developers, acidic finishers and replenishing solutions are not needed, waterless system will help reduce your pre-press cost and inventory low.
| Model | PROCEMAC | |||
|---|---|---|---|---|
| 400WL | 650WL | 800WL | 1100WL | |
| Max Width | 400 mm | 650 mm | 800mm | 1100mm |
| Min Length | 280 mm | 280 mm | 280mm | 280mm |
| Plate Thickness | 0.15 - 0.4mm | |||
| Processing Speed | 11-39 cm/min | |||
| Tank | Pre process: 8L, Develop: 9L, Post process: 10L, Water wash: 9L | Pre process: 13L, Develop: 15L, Post process: 16L, Water wash: 15L | Pre process: 22L, Develop: 25L, Post process: 27L, Water wash: 25L | Pre process: 35L, Develop: 40L, Post process: 42L, Water wash: 40L |
| Weight | 260 kg | 320 kg | 400 kg | 550 kg |
| Power | 220V 50Hz 20A | |||
| Power Consumption | 2.5KW | |||
Recommended
Frequently Asked Questions
What are the key specifications of Toray TORELIEF Dry Offset Plate Processor?
Max Width: 400 mm; Min Length: 280 mm; Plate Thickness: 0.15 - 0.4mm; Processing Speed: 11-39 cm/min; Weight: 260 kg; Power: 220V 50Hz 20A; Power Consumption: 2.5KW
