CTP Machine Plate Bridge
1. Exquisite Design
Small, simple and flexible. McLantis plate bridge is designed with optional components allowing you to configure a compact conveyor that meets your specific requirements.
2. Easy Installation
McLantis plate bridge comes complete with belts, motor and built-in power supply, and can be connected to a single phase power outlet.
3. Reliability
Reliable seamless belts on McLantis plate bridge for transporting plates without damage.
4. Customer size tailored
| Model | CONVEMAC | |
|---|---|---|
| 88C | 110C | |
| Max. Plate Size(mm) | 1050x880 | 1350x1100 |
| Mini. Plate Size(mm) | 400 | |
| Plate Thickness(mm) | 0.15-0.5 | |
| Speed(m/min) | 0-3 | |
| Height | adjustable | |
| Power | 220V single phase 50/60Hz 2A | |
| Weight(kg) | 85 | 110 |
| Machine Size(mm) | 1200x1150x888 | 1500x1450x888 |
| Packing Size(mm) | 1300x1250x1040 | 1600x1550x1040 |
Recommended
Frequently Asked Questions
What are the key specifications of CTP Machine Plate Bridge?
Max. Plate Size(mm): 1050x880; Mini. Plate Size(mm): 400; Plate Thickness(mm): 0.15-0.5; Speed(m/min): 0-3; Height: adjustable; Power: 220V single phase 50/60Hz 2A; Weight(kg): 85; Machine Size(mm): 1200x1150x888; Packing Size(mm): 1300x1250x1040
