Digital UV Roll to Roll Inkjet Printer
Nowadays the UV Printing is the trend of advertisement printing. As it can print more kinds of material, and guarantee much more longer lifetime, and gives very impressive printing result. Especially for this new arrival DIGIMAC JETUV Series Machine, Epson DX8 And Epson i3200-U industrial heads are available, 2m and 3.2m as option, meet the requirement of different printing. With i3200-U Heads, speed can be up to 130sqm/h. And with 6 or 8 DX8 heads, it will achieve amazing embossing effect. Which can be maximum 5 layers printing. Advanced technology, makes it to be your professional business partner.
| Model No. | DIGIMAC JET20UV | DIGIMAC JET20UVE | DIGIMAC JET32UV | DIGIMAC JET32UVE | |
|---|---|---|---|---|---|
| Printhead | 6 × | 4 × | |||
| Resolution(dpi) | 2880 dpi | ||||
| Width | 2000 mm MAX | 3200 mm MAX | |||
| Media | Type | Flex Banner, Vinyl, One Way Vision, Banner Cloth, Window Film, Mesh, Eco Solvent PP Paper, Eco Solvent Photo Paper… | |||
| Color | CMYK LC LM + W + V | CMYK/CMYK + W | |||
| Type | UV Ink | ||||
| Ink | Curing | High quality water cooling UV-LED Lamp | |||
| Test Color Mode | 3× | CMYK | |||
| Draft | 6 sqm/h | 8 sqm/h | 108 sqm/h | 130 sqm/h | |
| Standard | 4.5 sqm/h | 6 sqm/h | 80 sqm/h | 98 sqm/h | |
| Speed | Quality | 3.5 sqm/h | 4.5 sqm/h | 54 sqm/h | 64 sqm/h |
| Ink Supply System | Two advanced separate negative pressure systems (One for color and varnish, One for white). | ||||
| Cleaning System | Automatic Cleaning, Anti-Clogging Flash Function & Capping System | ||||
| Feed & Take Up | Automatic Media Feeding (Standard) & Take Up System (Standard) | ||||
| Environment | Temperature: 20-28°C, Humidity: 40-60% | ||||
| Rip Software | Photoprint | ||||
| Interface | USB3.0 | ||||
| Power | Machine 50/60Hz, 110/220V, 1500W | ||||
| Machine (mm) | 3770 x 920 x 1710 | 5170 x 920 x 1710 | 3770 x 920 x 1710 | 5170 x 920 x 1710 | |
| Size | Packing (mm) | 3870 x 1020 x 1940 | 5270 x 920 x 1940 | 3870 x 1020 x 1940 | 5270 x 920 x 1940 |
| Weight | Machine | 850KG | 1000KG | 850KG | 1000KG |
| Packing | 1100KG | 1300KG | 1100KG | 1300KG | |
Frequently Asked Questions
Which models of Digital UV Roll to Roll Inkjet Printer are available?
DIGIMAC JET20UV / DIGIMAC JET20UVE / DIGIMAC JET32UV / DIGIMAC JET32UVE
What are the key specifications of Digital UV Roll to Roll Inkjet Printer?
Printhead: 6 × Epson DX8 (8 Heads Available); Resolution(dpi): 2880 dpi; Media: Type; Ink: Curing; Speed: Quality; Ink Supply System: Two advanced separate negative pressure systems (One for color and varnish, One for white).; Cleaning System: Automatic Cleaning, Anti-Clogging Flash Function & Capping System; Feed & Take Up: Automatic Media Feeding (Standard) & Take Up System (Standard); Rip Software: Photoprint; Interface: USB3.0; Power: Machine 50/60Hz, 110/220V, 1500W; Size: Packing (mm)
