Blue Ray CTS Laser to Screen Direct Imaging Machine
| Model | MACSETTER | ||
|---|---|---|---|
| CTS750LTS | CTS1250 LTS | CTS1500LTS | |
| Max. Frame Size(mm) | 700x950 | 1100x1200 | 1600x2800 |
| Min. Frame Size(mm) | 200x300 | ||
| Max.Image Size(mm) | 650x900 | 1100x1250 | 1400x1900 |
| Frame Thickness | 25mm-60mm (can be customized) | ||
| Repeatability | 5um | ||
| Laser Type | UV LD 405nm | ||
| Laser Power | 48 / 64 / 96 / 128 laser channels | ||
| Imaging Unit | laser fiber optics | ||
| Emulsion over Mesh (EOM) | 3-400um (not include mesh thickness) | ||
| Imaging Time | 3 - 10 mins/m2 | ||
| Resolution | 360 / 720 DPI / 1440 DPI / 2400 DPI | ||
| Screening | 120 LPI | ||
| Supporting File | 1 bit tiff, BMP | ||
| Equipment Size | 1200* | 1900* | 2170* |
| Net Weight | 1000KG | 1500KG | 2200KG |
| Power | Single phase 220V, 50/60Hz, 2.5KW | ||
